CS1W-MD261 Programmable Controllers

Name: CS1D Processcontrol CPU Unit.
Specifications: CPU section,
Equivalent to the CS1D-CPU67H;
Loop control section,
LCB05D Operation method:
Function block method,
Number of function blocks:
500 blocks max.
Minimum operation cycle:
100 ms PID control method:
PID with two degrees of freedom,
(with autotuning function);
Current consumption: 5 V system, 1 CS1W-MD261. 04A;
26 V system, -- CS1W-MD261
Standards: UC1, N, CE.
Redundant CPU Units , Power Supply Units ,
Communications Units ,
and Expansion I/O Cables. Product name: CS1 Expansion Backplanes.
Specifications: For both CS/C200H-series,
Units; 3 slots.
Mountable configuration units:
Basic I/O Units, CS-series Basic I/O Unit,
Yes; C200H series Basic I/O Unit, Yes;
C200H Group-2 High density I/O Unit, Yes CS1W-MD261.
Special I/O Units: CS-series Special I/O Unit,
Yes; C200H series Special I/O Unit, Yes.
CPU Bus Units: CS-series CPU Bus Unit, Yes.
Current consumption: 5V system, 0.23A;
26 V system, --.
Standards: U, C, N, L, CE.
Multi-application Controllers:
From High-performance Machine C,
Highly Reliable Process Control. Unit type: CS1 Basic I/O Units CS1W-MD261.
Product name: Relay Output Units.
Specifications:12 to 24 VDC,
0.3A 64 outputs; Sinking.
Mountable Racks: CPU Rack, CS1W-BC,
@@3, Yes, @@2, Yes;
C200HX/HG/HE Expansion I/O Rack, No.
CS1 Expansion Rack, CS1W-BI,
@@3, Yes, @@2, Yes;
CS1 Long distance Expansion Rack, Yes;
SYSMAC BUS Slave Rack, No.
Words required: 4 words.
Current consumption: 5V system, 0.39A;
26 V system, --.
Standards: UC1, N, L, CE.
Multi-application Controllers:
From High-performance Machine C,
Highly Reliable Process Control. Specifications: Optical ring (HPCF cable).Unit classifi cation: CS1 CPU Bus Unit.
Product name:Controller Link Unit.
Specifications: Communications cable,
Wired shielded twisted-pair cable;
Communications type, Data links and,
message service; Duplex support, No.
Max. Units mountable per CPU Unit, 8.
No. of unit numbers allocated: 1.
Current consumption: 5V, 0.33A; 26V, --.
Standards: UC1, N, L, CE.
New Controller Link Units,
Now with 4,000 Send Words.
The Controller Link is an,
FA network that can send,
and receive large amounts,
of data easily and aat high speed CS1W-MD261.
The Controller Link supports data,
links that enable sharing data between,
PLCs and computers and a message service,
that enables sending and receiving,
data whenever required.
With Wired Controller Link Units,
systeems can be flexibly built by using,
Repeater Units to enable T branches,
long-distance wiring, and converting,
part of the network to optical cable CS1W-MD261.
