CS1W-NC113 Position Control Units
OMRON CS1W-NC113 Manual And Instructions
CS1W-NC113 datasheetPDF datasheet
CS1W-NC113 Installation Guide
CS1W-NC113 safety precautions
OMRON CS1W-NC113 Product information and technical parameters：
Brand: OMRON
Name: Position Control Units
Model: CS1W-NC113
Unit type: CS1 Special I/O Units.
name: Position control unit.
Specifications: Control method/Control,
output interface, Open-loop control by,
pulse train output/Open-collector output;
Number of control axes, 1 axis.
No. of unit numbers allocated: 1.
Current consumption: 5V, 0.25A; 26V, --.
Standards: U, C, N, L, CE.
High-speed, High-precision,
positioning with 1, 2, or 4 axes.
Versatile functions and superb,
performance enable the construction,
of compact, high-performance machines.
With its ultra-compact size of 31×90mm,
(W×H),this highly space-efficient Position,
Control Unit(PCU) enables up to 4 axes,
of motor control.
