E2E-C04N03-MC-B2 Small-diameter Proximity Sensor
OMRON E2E-C04N03-MC-B2 Manual And Instructions
E2E-C04N03-MC-B2 datasheetPDF datasheet
E2E-C04N03-MC-B2 INSTRUCTION sheet
OMRON E2E-C04N03-MC-B2 Product information and technical parameters：
Brand: OMRON
Name: Small-diameter Proximity Sensor
Model: E2E-C04N03-MC-B2
Appearance: 4 dia.
Sensing distance: 3 mm.
Connecting method: M8 Connector Models.
Cable specifications: --.
Operation mode: Nc.
Wire color /pin arrangement: 1: +V, 3: 0 V, 4: Control output.
Model: PNP output.
Ultra small size, but surprisingly easy installation!
With the addition of M4, 5.4-dia., 6.5-dia. size, unshielded,
pre-wired connector model, and connector model, a total of,
108 model variations are available.
High-speed response frequency stably detects moving,
objects: 5 kHz max.
Four indicator lamps for easier indicator positioning.
Special mounting brackets reduce time and efforts for,
installation.
Protective Stainless-steel Spiral Tube against wire,
breakage is available (M4, M5 only).
Models also available with standard cables that are 5 m long,
or with robot (bending-resistant) cables.
