E5EC-TQX4ASM-060 Digital temperature controller program
OMRON E5EC-TQX4ASM-060 Manual And Instructions
E5EC-TQX4ASM-060 datasheetPDF datasheet
E5EC-TQX4ASM-060 datasheetPDF datasheet
E5EC-TQX4ASM-060 RS-485 CompoWay/Flnstruction Manual
E5EC-TQX4ASM-060 Communications Manual
E5EC-TQX4ASM-060 User's Manual
E5EC-TQX4ASM-060 INSTRUCTION Manual
OMRON E5EC-TQX4ASM-060 Product information and technical parameters：
Brand: OMRON
Name: Digital temperature controller program
Model: E5EC-TQX4ASM-060
Size: 48 x 96mm.
Control output 1: voltage.
Auxiliary (alarm) output: 4.
Transfer output: -.
Event input: -.
Communication: -.
Break detection: -.
Power supply voltage: AC100 ~ 240V.
E5 - C series of new products program.
Maximum 256 segment of the program capacity,
Support for multiple applications.
Can be set up to 8 procedures (mode) x 32 (step) procedure.
The use of high 25mm (E5AC-T), 18mm (E5AC-T) PV display (white),
Improve visibility.
Not only on the top of the body, but also on the front,
The use of communication adapter cable (sold separately) connected to the computer after,
No power connection can be set.
It can be easily set by CX-Thermo (sold separately).
High speed sampling to achieve 50ms.
With auxiliary output (4 points), event input (maximum 6 points), the transmission output,
Support a variety of applications.
Slender fuselage depth 60mm.
Easy to connect with PLC through no program communication.
Combined temperature control device through component communication.
Add position proportional control type, also support control valve control.
