>> G3H-203SN-VD DC5-24 Solid State Relays
G3H-203SN-VD DC5-24 Solid State Relays
G3H-203SN-VD DC5-24 Introduce |
G3H-203SN-VD DC5-24 Catalog / Manual / Instructions / Software download
OMRON G3H-203SN-VD DC5-24 Manual And Instructions
G3H-203SN-VD DC5-24 datasheetPDF datasheet
OMRON G3H-203SN-VD DC5-24 Product information and technical parameters：
Brand: OMRON
Name: Solid State Relays
Model: G3H-203SN-VD DC5-24
Isolation: Photocoupler.
Zero cross function: Yes.
Indicator: Yes.
Rated output load: 3 A at 100 to 240 VAC *1.
Rated input voltage: 5 to 24 VDC.
New Models with International Standards.
Added to G3H Series (-VD in model number).
Same Profile as LY1 and LY2 Bi-power.
Relays.
Certified by UL, CSA, and VDE (models numbers with a suffix of “-VD”).
Socket type, same size as LY Power Relays.
Operation indicator provided to confirm input,
(models numbers with “N” before the suffix).
