H3Y-C Series Solid state timer
H3Y-C Series Introduce |
H3Y-C Series Model |
H3Y-C Series Catalog / Manual / Instructions / Software download
H3Y-C Series Catalog / Manual / Instructions / Software download
OMRON H3Y-C Series Manual And Instructions
H3Y-C Series datasheetPDF datasheet
OMRON H3Y-C Series Product information and technical parameters：
Brand: OMRON
Name: Solid state timer
Model: H3Y-C Series
Micro timer compatible with MY relay.
ON delay function, can accurately control the time.
Large and transparent time setting knob is easy to set up time.
Pin configuration compatible with MY power relay.
Access to UL, CSA and CCC certification in line with EN61812-1 and EMC standards.
