H3Y Series Solid-state Timer

Type: H7CZ.
Configuration: 1-stage preset counter.
External connections: 8-pin socket.
Settings: 1-stage.
Display digits: 6 digits.
Outputs: Contact output (SPDT).
Power supply voltage: 12 to 24 VDC/24 VAC.
Easy to Use and Easy to Read.
Basic Features.
Character height of 10 mm for better readability H3Y Series.
Operation is simplified by the Up Key for each digit.
Safety and Reliability H3Y Series
Power supply circuit and input circuits are isolated inside the Counter.
Set value limit function prevents unexpected operation of output,
devices caused by setting mistakes.
Output counter function helps in managing the service life of the,
Counter or the load.
Other Features.
Waterproof, dust-proof structure (UL508 Type 4X and IP66) H3Y Series.
Key protection. Timer input: PNP/NPN universal DC voltage input(4.5 to 30 VDC).
Display: 7-segment LCD with backlight.
Time range: 999h59min59s ←→ 9999h59.9min(switchable); Black body.
Seven digits, time range 0 to 3999d23.9h.
Dual time range: 999999.9 ←→ 3999d23.9h or,
999h59m59s ←→ 9999h59.9m. Rated supply voltage: 100 to 240 VAC.
Resetting system (See note H3Y Series. ): Self-resetting.
Control output: DPDT contact output (Time-limit output SPDT,
and switchable SPDT(time-limit - instantaneous)).
Time range: 1 s to 60 h (60 s, 6 min, 60 min, 6 h, 60 h).
Large Setting Dial and Moving Pointers Ideal,
for Easy Operation and Monitoring.
Incorporating an easy-to-see large setting dial with moving pointers.
Wide time-setting range of 0.2 s to 60 h.
(available through three time-range model types).
Wide AC power supply range (100 to 240 VAC).
IP65 watertight and dust-tight front panel.
Approved by UL and CSA.
Conforms to EN61812-1 and IEC60664-1.
4 kV for Low Vooltage, and EMC Directives H3Y Series.
Conforms to EMC standards.
Six-language instruction manual provided.
Programmable contact enables the building of a self-holding,
relay circuit as well as built-in instantaneous contact. (-NS).
Memory reteention (-NSR) H3Y Series.
Finger protection terminal block.
Enables easy sequence checks through instantaneous outputs.
for a zero set value at any time range.
