LY Series Bi-power Relays

Name: Cycle Control Unit.
Isolation transformer: Yes.
Rated power supply voltage: 100 to 240 VAC.
Refer to Safety Precautions for All Power Controllers.
Used in Combination with the G3PA to.
Enable High-precision Temperature Contro.
Use cycle control to achieve power control with little noise.
Used in combination with the G3PA to connect to single- and,
three-phase loads LY Series.
Three types of input method available: Internal adjuster,
external adjuster, or DC signals from 4 to 20 mA LY Series
Streamline design. Both DIN track mounting and screw,
mounting possible.
Use linking terminals for close mounting of the G3PA.
Built-in isolation transformer.
Power supply range: 100 to 240 V. Standard certification: No LY Series.
Insulation mode: three end two-way photoelectric switch.
Zero trigger function: No.
Action indicator: there.
Applicable load of output: DC24 2.5A ~ 240V.
Input rated voltage: DC12 ~ 24V.
With the LY1, LY2 large power relay with the same shape of the G3H series, the new international standard certification (-VD type).
Achieved UL, CSA, EN (VDE certification) standard certification LY Series. (type -VD)
Socket terminal type of same size with LY (1 pole, 2 pole type).
A model with an action indicator to check the status of the input. (type N)Structure: Relays with Plug-in Terminals.
Classification: Models with diode for coil surge,
absorption (DC coil specification only).
Number of poles: 3.
Power-switching Compact.
General-purpose Relays.
The standard models include models that are,
compliant with the UL, CSA, and SEV safety.
standards and with the Electrical Appliances and,
Material Safety Act.
Equipped with an arc barrier for arc interruption.
Withstand voltages up to 2,000 V.
New built-in diode and built-in CR circuit models have,
joined the series.
The lineeup also includes models that are compliant,
with the LR and VDE safety standards LY Series.
Single-pole and double-pole models have AC4,
ratings and DC2 ratings (operating coil ratings:
100/110 VAC, 110/120 VAC, 200/220 VAC, 220/240 VAC,
and 1100/110 VDC) LY Series.
Three-pole and four-pole models have AC4 ratings,
and DC2 ratings (operating coil ratings: 100/110,
VAC, 200/220 VAC and 100/110 VDC).
