>> S8VS-24024A Switch Mode Power Supply
S8VS-24024A Switch Mode Power Supply
OMRON S8VS-24024A Manual And Instructions
S8VS-24024A datasheetPDF datasheet
S8VS-24024A Installation and Operating Manual
S8VS-24024A Installation and Operating Manual
OMRON S8VS-24024A Product information and technical parameters：
Brand: OMRON
Name: Switch Mode Power Supply
Model: S8VS-24024A
Power ratings: 240 W.
Input voltage: 100 to 240 VAC(allowable range: 85 to 264 VAC or 80 to 370 VDC*1).
Output voltage: 24 V.
Output current: 10 A.
Alarm output *2: Sinking.
UL Class 2 Output standards: --.
Model number(screw terminal block).
60/90/120/180/240/480-W Models.
New Models with Indication.
Monitor and Simple Functions for.
Easy System Commissioning.
New 90-W models with indication monitor that.
conform to UL Class 2 Output standards.
New models with screwless terminal blocks and,
indication monitor.
Status displayed on 3-digit, 7-segment display.
Safety standards: UL 508/60950-1,
CSA C22.2 No. 107.1/60950-1,
EN 50178 (= VDE 0160), EN 60950-1 (= VDE 0805 Teil 1).
Input conditions: DC input is also possible from 80 to 370 VDC.
(Not compliant with EC Directives and other safety standards.)
...More relevant models >>>>
