SRT2-ID32ML-1 Transistor Remote I/O Terminals with Connectors
OMRON SRT2-ID32ML-1 Manual And Instructions
SRT2-ID32ML-1 datasheetPDF datasheet
SRT2-ID32ML-1 SETUP MANUAL
SRT2-ID32ML-1 User's Manual
OMRON SRT2-ID32ML-1 Product information and technical parameters：
Brand: OMRON
Name: Transistor Remote I/O Terminals with Connectors
Model: SRT2-ID32ML-1
I/O classification: Input.
Internal I/O circuit common: PNP (– common).
I/O points: 32.
I/O connection method: MIL connector.
Rated voltage for communications power supply: 24 VDC.
Rated voltage for I/O power supply: 24 VDC.
Applicable relay: G3DZ-2R6PL.
Subminiature 32-point Remote Terminal with Connectors.
Compact dimensions: 35 × 60 × 80 (W × D × H).
Long-distance and high-speed communications modes available.
Downsizing enabled with 32-point MIL connector for I/O connection.
