OMRON DRT2-MD32SLH Product information and technical parameters：
Brand: OMRON
Name: Screw-less Clamp Terminals with Transistors
Model: DRT2-MD32SLH
Short/disconnection detection: Supported.
Specifications: I/O, NPN (input: + common, output: - common), 16 inputs/16 outputs.
I/O connections: Clamp terminals.
Rated internal circuit power supply voltage:
Supplied from communications connector.
Rated I/O power supply voltage: 24 VDC.
Reduced Wiring and Labor on Factory Sites with Screw-less Terminal Wiring.
Screw-less structure eliminates tightening work.
Detachable terminal blocks for easier maintenance.
Single-step wiring by simply inserting pole terminals.
