>> DRT2-OD16SLH-1 Screw-less Clamp Terminals with Transistors
DRT2-OD16SLH-1 Screw-less Clamp Terminals with Transistors
OMRON DRT2-OD16SLH-1 Manual And Instructions
DRT2-OD16SLH-1 datasheetPDF datasheet
OMRON DRT2-OD16SLH-1 Product information and technical parameters：
Brand: OMRON
Name: Screw-less Clamp Terminals with Transistors
Model: DRT2-OD16SLH-1
Short/disconnection detection: Supported.
Specifications: Outputs, PNP (+ common), 16 points.
I/O connections: Clamp terminals.
Rated internal circuit power supply voltage:
Supplied from communications connector.
Rated I/O power supply voltage: 24 VDC.
Reduced Wiring and Labor on Factory Sites with Screw-less Terminal Wiring.
Screw-less structure eliminates tightening work.
Detachable terminal blocks for easier maintenance.
Single-step wiring by simply inserting pole terminals.
