>> E5AZ-Q3T Digital Temperature Controllers
E5AZ-Q3T Digital Temperature Controllers
OMRON E5AZ-Q3T Manual And Instructions
E5AZ-Q3T datasheetPDF datasheet
E5AZ-Q3T User's Manual
E5AZ-Q3T Communications Manual
OMRON E5AZ-Q3T Product information and technical parameters：
Brand: OMRON
Name: Digital Temperature Controllers
Model: E5AZ-Q3T
Size: 1/4 DIN 96 × 96 × 78 (W × H × D).
Power supply voltage: 100 to 240 VAC.
Input type: Thermocouple or Resistance thermometer.
Alarm output: 3.
Control output: Voltage output(for driving SSR).
Functions: Heater burnout, No; Mounting option units, No.
Previous model: E5AZ-Q3 E5AZ-A3 + E53-AZQ.
These Best-selling General,
purpose Temperature Controllers,
Are Now Even Better.
Controllers now available with analog inputs.
Faster sampling at 250 ms.
Transfer output provided for easy output to recorders.
Models available with a loop break alarm (LBA) and,
heater short alarm (HS alarm).
Manual output provided.
Easy setting with 11-segment displays.
New protocol called Modbus is installed in the,
models with communications.
USB-Serial conversion cable is available.
Note: Refer to Precautions on page 33.
