SRT2-ID16 Transistor Remote I/O Terminals
OMRON SRT2-ID16 Manual And Instructions
SRT2-ID16 datasheetPDF datasheet
SRT2-ID16 SETUP MANUAL
SRT2-ID16 User's Manual
OMRON SRT2-ID16 Product information and technical parameters：
Brand: OMRON
Name: Transistor Remote I/O Terminals
Model: SRT2-ID16
I/O classification: Input.
Internal I/O circuit common: NPN (+ common).
I/O points: 16.
Rated voltage: 24 VDC.
I/O rated voltage: 24 VDC.
Long-distance Communications Supported by SRT2 Models,
(Long-distance/High-speed Communications Selection).
Ultra-compact at 80 x 48 x 50 (W x H x D) mm for,
4-point and 8-point terminals and 105 x 48 x 50,
(W x H x D) mm for 16-point terminals.
Two independent power supplies can be used,
because the I/O terminals are insulated from the internal circuits.
DIN track mounting and screw mounting are both supported.
